BERTOLINI TMG 240
Code: 1456
Product detailed description
Bertolini TMG 3540 high-pressure pump
This product is listed as Bertolini TMG 240. The catalogue code 07.1602.97.A identifies the TMG 3540 version with a 1-inch hollow shaft for a compatible SAE J609 engine connection.
Technical specifications
- Flow rate: 15 L/min at 3450 rpm.
- Maximum pressure: 240 bar.
- Rated pump power: 7 kW.
- Inlet: 1/2 inch BSP; outlet: 3/8 inch BSP.
- Maximum inlet water temperature: 60 °C.
Suitable applications include pressure washing and industrial cleaning. Check the engine flange, shaft dimensions, direction of rotation and drive requirements before installation. The 7 kW figure is the pump power requirement, not a universal engine selection.
Additional parameters
| Category: | PUMPS |
|---|---|
| Flow rate: | 15 L/min |
| Pressure Max: | 240 bar |
| RPM: | 3450 rpm |
| Power: | 7 kW |
Bertolini: pumps for washing and agriculture
Bertolini develops pumps for professional cleaning, industrial use and agriculture. Its portfolio spans plunger and diaphragm technologies, allowing equipment designers to choose a pumping principle suited to the working pressure and the liquid being handled.
Product range and applications
High-pressure pump families are relevant to pressure washing and industrial cleaning, while diaphragm pumps are widely used in agricultural spraying systems. The broader range includes regulation and control equipment for spraying installations. Different series are designed for different operating conditions and materials compatibility.
Selection and system integration
Compare required flow and pressure with the rated pump speed and available drive. When handling chemical mixtures, verify the wetted materials and diaphragm or seal specification. For servicing, identify the complete model and use its exploded drawing to select the correct components.
See our high-pressure pump category for cleaning applications.
