Interpump W2030
Code: 1483
Product detailed description
Interpump W2030 high-pressure plunger pump
The Interpump W2030 delivers 30 L/min at a maximum pressure of 200 bar and 1450 RPM. Its official power rating is 11.02 kW (15 hp). The pump measures 340.5 × 242.5 × 189.5 mm and weighs 18.5 kg.
Verified technical specifications
- Flow: 30 L/min (7.92 US gpm)
- Maximum pressure: 200 bar (20 MPa / 2900 psi)
- Speed: 1450 RPM
- Power: 11.02 kW (15 hp)
- Dimensions: 340.5 × 242.5 × 189.5 mm
- Weight: 18.5 kg
Compare operating points
For a lower flow of 21 L/min at the same maximum pressure of 200 bar, compare the Interpump WS202. Both ratings are at 1450 rpm. Check drive power and mounting compatibility before choosing another model.
Official Interpump documentation
- Dimensions and shaft drawing (PDF) — manufacturer reference configuration: single male keyed shaft.
- Interpump W2030 technical data and documents — performance curve, manuals, CAD files and spare-parts list.
Confirm the supplied shaft configuration and installation dimensions before ordering.
Compare more Interpump high-pressure pumps or review the official Interpump W2030 specifications.
Additional parameters
| Category: | PUMPS |
|---|---|
| Flow rate: | 30 L/min |
| Pressure Max: | 200 bar |
| RPM: | 1450 rpm |
| Power: | 11.02 kW / 15 hp |
Interpump: Italian high-pressure pump engineering
Interpump is an Italian name in professional high-pressure piston and plunger pumps. Its development of compact pumps with ceramic pistons helped shape modern pressure washing equipment. Today, the brand serves equipment manufacturers, service companies and operators of industrial cleaning installations.
Technology and applications
Interpump pumps are used to deliver pressurised water in professional washing and industrial systems. The wider Interpump Group also operates in water jetting and hydraulics, while the pump brand is particularly relevant to pressure washers, vehicle washing and industrial cleaning.
- High-pressure plunger pumps for professional cleaning equipment.
- Pumping solutions for car wash installations and industrial washing.
- Application-specific pump configurations and service components.
Selecting a pump or replacement parts
Check rated flow, pressure, rotational speed, inlet temperature and drive arrangement against the intended duty. Similar-looking pumps can have different shafts, mounting dimensions and seal specifications. The complete model code and parts diagram are therefore essential when ordering service kits or replacing an existing unit.
Visit our Interpump high-pressure pumps category to compare the available models and their technical specifications.
