MECLINE SVL 35 RELIEF VALVE
Code: 2430
Product detailed description
Mecline SVL 35 relief valve
The Mecline SVL 35 by Tecomec is a brass pressure-relief valve for professional high-pressure water systems. Manufacturer part number: 4073500024.
Technical specifications
- Rated pressure: 310 bar.
- Permissible pressure: 350 bar.
- Minimum adjustable pressure: 70 bar.
- Rated flow: 50 L/min.
- Rated temperature: 90 °C.
- Inlet and discharge: G 3/8 female.
Use the rated operating values when selecting the valve for a pressure washer or car wash installation. The 350 bar permissible pressure must not be confused with the 310 bar rated pressure. Match the relief setting and discharge arrangement to the complete system.
Additional parameters
| Category: | VALVES |
|---|---|
| Rated pressure (bar): | 310 |
| Permissible pressure (bar): | 350 |
| Max flow rate (l/min): | 50 |
| Body: | Brass |
| Inlet: | G 3/8" F |
| By-pass: | G 3/8" F |
Tecomec: components for cleaning, spraying and outdoor equipment
Tecomec develops components and accessories across cleaning, agriculture, forestry and gardening. Its portfolio therefore reaches beyond pressure washing: it includes products for spraying machinery, chainsaw maintenance and brushcutters as well as professional cleaning equipment. This broader focus connects fluid handling with the maintenance and operation of outdoor machinery.
Product range and applications
The Mecline range serves pressure washers, industrial washing equipment and car wash applications. Geoline focuses on agricultural spraying and related liquid handling tasks. Other Tecomec product groups support forestry and gardening equipment, allowing the brand to address several distinct technical applications.
Selection and system integration
Choose parts by their specific product family and intended machine. For cleaning and spraying components, verify working pressure, flow, temperature, connections and liquid compatibility. Replacement parts should be matched to the original model and technical documentation, because components serving different applications are not automatically interchangeable.
For cleaning installations, browse our unloader valves and guns, lances and brushes.
