INJECTOR ST-168 (NOZZLES DOSING)
Code: 2374
Product detailed description
The INJECTOR ST-168 (NOZZLES DOSING) by R+M Suttner enables precise chemical control for industrial cleaning systems through an integrated compressed air connection. This unit is engineered with a 9 mm suction port to ensure consistent flow during operation.
Chemical dosing is managed via 10 interchangeable dosing inserts, allowing for precise calibration within a range of 0.5 – 2.0 mm. Users can select the nozzle size to meet specific application requirements, with additional injection nozzles ranging from 1.2 to 2.8 mm available upon request.
For technical specifications and installation guidance, please refer to the documentation provided below:
ST167_168 User manual
Additional parameters
| Category: | Injectors |
|---|---|
| Inlet: | 1/2" F |
| Outlet: | 1/2" F |
| Max pressure (bar): | 350 |
| Max temperature (°C): | 100 |
R+M Suttner: accessories for professional cleaning
R+M Suttner provides components and accessories for professional cleaning equipment. The portfolio covers high-pressure washing, vehicle cleaning and foam application, with products that connect the machine to the operator and the surface being cleaned. It is relevant to equipment assembly, maintenance and the adaptation of existing installations.
Product range and applications
The range includes spray guns, lances, nozzles, hoses, couplings and accessories for foam cleaning. Different product families address general pressure washing as well as specialised cleaning and hygiene tasks. Selecting coordinated components helps establish the required spray behaviour, reach and handling characteristics.
Selection and system integration
Check the pressure, flow and temperature limits of every part in the circuit, including hose assemblies and connectors. Material compatibility matters when detergents or disinfectants are used. Connection standards, nozzle sizing and the ergonomics of the gun and lance should be considered together for the intended working conditions.
