UDOR CC 70/15 S
Code: 1461
Product detailed description
UDOR CC 70/15 S high-flow pump
The CC 70/15 S is a plunger pump with a rated flow of 70 L/min at 1450 rpm and a maximum pressure of 150 bar.
Technical specifications
- Flow rate: 70 L/min.
- Maximum pressure: 150 bar.
- Pump speed: 1450 rpm.
- Solid ceramic plungers.
- High- and low-pressure water seals.
- Side oil-level sight glass.
Power rating and drive selection
The existing 20.1 kW listing is consistent with the 27.0 EBHP figure published by UDOR USA. UDOR’s model-specific technical sheet (revision 00, 3 April 2019) instead lists 20.4 kW / 27.7 HP. Confirm the rating for the supplied version before sizing the drive; these figures must not be treated as an interchangeable motor recommendation.
Official documentation
UDOR CC 70/15 S technical sheet and dimensions (PDF) · UDOR USA C-series model table
Check the complete pump designation, shaft arrangement and installation dimensions against the relevant documentation before ordering a replacement.
Additional parameters
| Category: | PUMPS |
|---|---|
| Weight: | 9 kg |
| Flow rate: | 70 L/min |
| Pressure Max: | 150 bar |
| RPM: | 1450 min |
| Power: | 20,1 kw |
UDOR: plunger and diaphragm pump expertise
UDOR is an Italian pump manufacturer based in Rubiera. Founded in 1966, the company designs and manufactures diaphragm and plunger pumps for water and application-specific liquids at low, medium and high pressure.
Two pump technologies, different duties
UDOR diaphragm pumps are used in spraying and chemical or agricultural applications, while its plunger pumps serve high-pressure cleaning and water jetting. The distinction matters: the correct technology depends on the liquid, required pressure and working conditions.
- Plunger pumps for pressure washing and industrial cleaning.
- Diaphragm pumps for agricultural spraying and compatible chemical solutions.
- Application-specific pumps for firefighting and de-icing systems.
- Motorpump units, mounting options and pressure regulation accessories.
Choosing and maintaining a UDOR pump
Select the pump by operating pressure, flow rate, speed and drive connection. Verify compatibility of the head, diaphragms or seals with the liquid being pumped. For service work, use the full model designation and the manufacturer’s exploded drawing to identify replacement components.
