CAT 350
Code: 334
Product detailed description
CAT Pumps 350 triplex plunger pump
The CAT Pumps 350 is a positive-displacement triplex plunger pump rated for a maximum flow of 18.9 L/min (5 gpm), a maximum pressure of 103 bar (1500 psi) and 1725 RPM.
Verified technical specifications
- Maximum flow: 18.9 L/min (5 gpm)
- Maximum pressure: 103 bar (1500 psi)
- Speed: 1725 RPM
- Inlet port: 1/2-inch NPT(F)
- Discharge port: 3/8-inch NPT(F)
- Drive options: belt, clutch, flexible coupling and bellhousing
The model uses a chrome-plated brass manifold, 304 stainless steel valve assemblies, solid ceramic plungers and standard NBR (Buna-N) seals and O-rings. Confirm the drive arrangement, port standard and system requirements before ordering; universal compatibility is not assumed.
Compare more CAT high-pressure pumps or review the official CAT Pumps 350 specifications.
Additional parameters
| Category: | PUMPS |
|---|---|
| Weight: | 9 kg |
| Flow rate: | 18.9 L/min |
| Pressure Max: | 103 bar |
| RPM: | 1725 rpm |
| Inlet port: | 1/2-inch NPT(F) |
| Discharge port: | 3/8-inch NPT(F) |
| Port standard: | NPT(F) |
CAT Pumps: triplex pumps for demanding applications
CAT Pumps develops high-pressure positive displacement pumps and pumping systems for professional and industrial use. The brand is associated with triplex piston and plunger pump technology, serviceable construction and a broad choice of configurations for different liquids and operating conditions.
Where CAT Pumps are used
Applications extend well beyond vehicle washing. The manufacturer supplies pumping solutions for industrial cleaning, reverse osmosis, food and beverage processing, misting and manufacturing. Specialised models also serve mobile equipment and oil and gas installations.
- Pressure washing and self-service or automatic car wash systems.
- Water treatment, reverse osmosis and controlled liquid delivery.
- Misting, cooling and humidity control.
- Industrial washdown and equipment cleaning.
Materials, installation and servicing
Different pump families use different wetted materials and seals. Select the configuration for the liquid, temperature, pressure and required flow rather than assuming that every CAT pump is suitable for the same service. Drive speed, shaft dimensions and inlet conditions must also match the installation.
Browse our CAT high-pressure pumps to compare models. For maintenance, use the pump model and parts drawing to identify the correct seal, valve or piston components.
